Snap Lock Roof Coping System

Snap lock roof coping. The picture shows snap lock roof coping. installed over brick wall with wide wood blocking.

Snap Lock Roof Coping Product Features

  • Snap Lock roof coping is formed in 10 ft. sections and joined to allow for longitudinal expansion and contraction
  • Heavy gauge steel anchors eliminate the necessity to use exposed fasteners
  • The coping cap has no penetrations on either side
  • 12 in. wide hold down anchors are mechanically fastened every 4 ft.
  • Individual coping sections are joined with 6 in. back-up plates
  • Back-up plates can be factory pre-clinched for ease of installation and to avoid errors during mounting
  • Wide variety of colors and material thicknesses is available with short lead times
  • Snap Lock roof coping system of practically any width and height can be fabricated

Snap Lock Roof Coping Sketch Drawing

Several types are available. Please click on individual tabs to view.

Snap lock roof coping sloped sketch drawing. The image shows a sketch of metal coping installed over parapet wall with existing slope.

Snap lock roof coping level sketch drawing. The image shows a sketch of metal coping installed level over parapet wall.

Simple system existing slope sheet metal coping sketch drawing. The image shows a sketch of metal coping installed over parapet wall with existing slope.

Simple system sloped from center sheet metal coping sketch drawing. The image shows a sketch of metal coping installed over parapet wall with existing slope from center.

Materials

  • 27 Kynar 500 colors from Englert Color Chart are stocked in 0.032", 0.040", 0.050" Aluminum, 22 & 24 GA Steel
  • Mill finish products can be fabricated in various metal thicknesses
  • Stainless Steel, Copper and Zink are available with short lead times
  • Snap Lock roof coping can also be fabricated from flat stock purchased off any available sheet metal manufacturer on the market (Drexel Metals, ATAS, PAC-CLAD, Firestone, etc.)

Warranty

  • 35 year color warranty when fabricated from Englert flat stock
  • Lifetime Total System warranty is available on commercial projects

Documents

Product Data.pdfSnap Lock Roof Coping Data Sheet
Quote Request Form.pdfSnap Lock Roof Coping Interactive Quote Request Form
